Cerwin Vega HED300.2

300W HED Series 1-Ch Amplifier

Description

FEATURES:

  • HED Series 2-Channel Class AB Car Amplifier
  • RMS Power Rating:
    • 4 ohms: 40 watts x 2 chan.
    • 2 ohms: 75 watts x 2 chan.
    • Bridged, 4 ohms: 150 watts x 1 chan.
  • Max power output: 300 watts x 1 chan.
  • PWM MOSFET power supply
  • Remote bass level input (remote level control sold separately)
  • LED power (green) and protect (red) indicators
  • Vega Bass Boost (0 to +12 dB bass boost at 45 Hz)
  • Soft Start Turn-on
  • 2/1 Channel operation
  • Speaker-level (high-level) inputs with signal sensing for automatic turn-on
  • Preamp RCA outputs to daisy chain multiple amps
  • 3-Way System Protection circuitry
  • High-density aluminum alloy heatsink for extreme heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Input sensitivity:
    • Low level: 122mV-5V
    • High level: 3.8V-20V
  • Crossover selection switch
  • Variable high-pass filter (50-250 Hz, 12 dB/octave)
  • Variable low-pass filter (50-250 Hz, 12 dB/octave)
  • Damping factor: >363 at 50 Hz
  • Frequency response: 20-49,000 Hz
  • Dimensions: 11-5/8″L x 9-7/16″W x 2-1/8″H
  • 8-gauge power and ground wiring is required for installation.
