Cerwin Vega HED 500.1
500W MAX Amplifier HED Series Class AB
Description
FEATURES:
- HED Series Monoblock Class AB Car Amplifier
- RMS Power Rating:
- 4 ohms: 150 watts x 1 chan.
- 2 ohms: 250 watts x 1 chan.
- Max power output: 500 watts x 1 chan.
- PWM MOSFET power supply
- Remote bass level control included
- LED power (green) and protect (red) indicators
- Vega Bass Boost (0 to +12 dB bass boost at 45 Hz)
- Soft Start Turn-on
- Mono channel operation
- Speaker-level (high-level) inputs with signal sensing for automatic turn-on
- Preamp RCA outputs to daisy chain multiple amps
- 3-Way System Protection circuitry
- High-density aluminum alloy heatsink for extreme heat dissipation
- Nickel-plated RCA level inputs
- Nickel-plated screw terminals
- Input sensitivity:
- Low level: 112mV-5.4V
- High level: 3.55V-20V
- Variable low-pass filter (50-250 Hz, 12 dB/octave)
- Variable sub-sonic filter (15-55 Hz, 12 dB/octave)
- Damping factor: >222 at 50 Hz
- Frequency response: 17-255 Hz
- Dimensions: 11-5/8″L x 9-7/16″W x 2-1/8″H
- 8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website (SonicElectronix.com) when purchased together with this amplifier.
